ASI 0336 Lavatory Mounted Manual Foam Soap Dispenser with 4" Spout, 34 oz
ASI 0336 Manual Foam Soap Dispenser image

Large Quantity, Item Customization, or Government Project? Request A Quote or give us a call at 920-569-0895
List Price: $175.10
Our Price: $96.30
Savings: $78.80
Manufacturer: ASI
Availability: Usually Ships in 2-3 Business Days



Product Code: 0336
Qty:

Description Technical Specs A Note from the Manufacturer

ASI 0336 Lavatory Mounted Manual Foam Soap Dispenser with 4" Spout, 34 oz
Soap Recommendation
Foam soap
pH Range: 5.5-8.5
Viscosity Range mPas-cP: 1-100

Construction
Lavatory mounted foam soap dispenser plunger cap, stem and body, spout, escutcheon and base sleeve shall be shiny bright finish stainless steel with rubber “duck bill” check valves and O-ring seals. Valve body, internal parts, basin nut, threaded shank shall be molded plastic. Spring, escutcheon washer, stem retainer collar and screw shall be stainless steel. Soap container shall be translucent, shatter-resistant HDPE.

Valve operation shall comply with 2010 ADA Accessibility Standards by requiring no more than 5 lbsf (22.2 Newtons) of pressure to actuate without grasping or twisting by operator.
Capacity: 34 oz.

Installation
Unit is typically located adjacent to a flush mounted lavatory, through 7/8" Diameter cut out (by others) in counter top. The threaded shank allows for installation in counter tops up to 3-1/4" thick.

Operation
Soap is manually dispensed by pushing down on the Plunger Cap. Dispenser is refilled by either unscrewing the Stem & Body to expose the internal fill opening or by removing the tank from under vanity. Soap will continue to feed properly until soap level is below top of intake bottom fitting. Soap supply is replenished manually on a schedule determined by maintenance needs.

Warranty
One (1) Year Manufacturer's Warranty - Warranted to be free of defects in material or workmanship for one (1) year from date of sale.

Foam Soap Dispenser Options
Model 0336-D Foam Soap Dispenser with 6" spout and 34 oz globe

Liquid Soap Dispenser Options
Model 0332 Liquid Soap Dispenser has 34 oz globe with 4" spout
Model 0332-C Liquid Soap Dispenser has 20 oz globe with 4" spout
Model 0332-D Liquid Soap Dispenser has 34 oz globe with 6" spout
Model 0332-CD Liquid Soap Dispenser has 20 oz globe with 6"
spout

Accessories
ASI 0332-18 Replacement Polyethylene Globe for Lavatory Mounted Soap Dispensers, 34 oz ASI 0332-64 1" High Spacer for ASI Lavatory Mounted Soap Dispenser Series 0332 ASI 0332-20 Adapter for 0332 Series Soap Dispensers
Our Price: $4.60
Our Price: $10.30
Our Price: $5.00
ASI 0332-18 Replacement Polyethylene Globe ASI 0332-64 Soap Dispenser Spacer ASI 0332-20 Adapter for 0332 Series Soap Dispensers
