ASI 7305-2S Two Roll Toilet Paper Holder

Home > Toilet Tissue Dispensers > Multiple Roll >

ASI 7305-2S Surface Mounted ADA Compliant Toilet Tissue Dispenser, Satin Finish

List Price: $45.00

Our Price: $24.70

Savings: $20.30

Manufacturer: ASI
Availability: Usually Ships in 2-3 Business Days

Product Code: 7305-2S

Qty:

Description

Technical Specs

ASI 7305-2S Surface Mounted ADA Compliant Toilet Tissue Dispenser, Satin Stainless Steel Finish

For Single Roll Option see Model 7305-S

Construction
Dual roll toilet paper roll holder is fabricated of 18-8, type 304 stainless steel alloy. Posts are fabricated of 1/2" x 1" rectangular tubing. Stainless steel set screws are provided for the bottom of the flanges to lock them to the mounting plates which are 18 gauge stainless steel. The rollers are chrome plated with high impact resistant ABS plastic. All surfaces are satin stainless steel finish.

Installation
Surface mount unit on wall using No. 10 self threading flat, oval, or pan head screws (provided by others) through holes provided in mounting plates into suitable prepared mountings (by others) or other suitable mounting hardware (by others) to suit wall conditions. Hang post and flange assemblies on mounting plates and tighten set screws to lock units to plates.

For compliance with 2010 ADA Accessibility Standards, 2015 ABA Standards, and ANSI 117.1 Standards install unit so that center line of dispenser is 7" Min to 9" Max in front of toilet and dispenser center is 15" Min AFF to 48" Max AFF.

Operation
Spring loaded spindles revolve freely and hold rolls until core is removed.

Warranty
One (1) Year Manufacturer's Warranty - Warranted to be free of defects in material or workmanship for one (1) year from date of sale.

Options
Model 7305-2B is the same except with bright polish finish.
